Description

The Convectair Piccolo blower designed for the bathroom

The Convectair Piccolo is our thinnest built-in blower, just 2 cm thick. Specially suitable for bathrooms with limited wall space, its heating power is 750 watts activated by the electronic thermostat and 1,500 watts when the timer is activated. No more chills!





Punctual power thanks to the wind tunnel

The generally more compact convectair blower allows rapid heating and more intense air movement. Its heating element, with low thermal inertia, allows power to be concentrated in a small space. The heat of the element is directly communicated to the air pushed by a turbine. Coupled with a timer, the blowers really give heating ‘on demand’. A Convectair Piccolo maintains the required temperature without leaving room for the slightest variations. Thanks to the electronic thermostat sensitive to the nearest 1/10 ° C, the occupants move in a stable environment, as long as they want and without playing with the thermostat, whatever the variations of the outside climate. Convectairs intended for the bathroom are designed so as not to be affected by splashes. Large appliances have an easy to access control panel, but out of the reach of children. Smaller models and natural convection appliances have locking panels. Finally, all the blowers (except the Soprano) operate with a timer, so you can’t forget to turn them off.



Its precision

Thanks to the backlit electronic thermostat sensitive to 1/10 ° C near the Piccolo and its probe placed 12 inches from the ground to detect the coldest air, you will evolve in a stable, precise and constant atmosphere.

Safety in the bathroom

The Piccolo is designed so as not to be affected by splashing water and its heating element is inaccessible to children’s fingers. Its lockable thermostat has a safety device in case of overheating. The installation must comply with the national and local standards in force and respect the minimum clearances between the water sources and the device.



Convectair Piccolo Heating Element

Total capacity 1500W / 750W

Fan (750 W) Resistance with low thermal inertia combined with an all-steel tangential turbine.

Accelerated heating (1500 W) on request Resistance with low thermal inertia combined with an all-steel tangential turbine.



Regulation

Integrated electronic thermostat with proportional action for basic heating.

Electronic timer from 5 to 90 minutes for accelerated heating, with light indicator.

Programmer Compatible with the Programmer, using a pilot wire.



Control panel

Location Located on the front of the device.

Backlit digital display with lockable controls by key combination.

On-Off button with indicator light.

+ And – button Controls the set temperature.

Timer “Hourglass” button with indicator light.

24h button Recording of the “Chrono” mode with indicator light, for daily preheating of the bathroom.

Lock indicator.

Heating indicator.



Housing

Steel coated with anti-corrosion polyester / epoxy resin and resistant to UV rays.

Safe enclosure with rounded corners and slim profile, for safe installation in the bathroom.

Air outlet through the lower opening directing the hot air flow to the floor in the center of the room.

Color BB = White



Installation and connection

Installation height: 12 ” (30 cm).

Minimum clearances: Front: 60 cm (24 in) – Sides: 10 cm (4 in) – Height: 20 cm (8 in).

Installation recessed between the studs of a wall, in a rectangular opening 37.2 cm (14 5/8 in) in height; 31.5 cm (12 3/8 in) wide.

Depth required: 8.6 cm (3 3/8 in).

Direct connection to the power cable by knockout in the upper left. Removable front for installation, fixing and connection from the front.



The Convectair guarantee

2 years against all vices

5 years for heating elements

Additional information

Weight	12.4 lbs
Dimensions	15 × 1 × 15.75 in

Brochure

Installation guide
